W12SNC-8x2000
| Quantity: | |
|---|---|
This CNC metal sheet rolling machine is fully hydraulically driven, digitally controlled, with advanced structure, superior performance and high efficiency. It is at the leading level in the same industry both at home and abroad. Features of our four-roller plate rolling machine:
1. Side roller arc movement increases work stability
2. Both sides of the pressing roller are controlled by absolute encoders.
The following users are suitable for using this CNC four-roller rolling machine:
1.The user who uses the plate rolling machine for the first time because it is the easiest plate rolling machine
2.The operator lacks inspection requirements for high productivity
3.Requires high precision and improves the quality
4.Hope that there is only one operator to reduce labor costs
5. Due to the large board size, high production volume or for safety reasons, a handling device, feeding device, and feeding device are required.
Item | Unit | Data |
Model | W12CNC-8x2000 | |
Yield limit of steel plate | Mpa | σs ≤245 |
Maximum width of bend steel plate | mm | 2010 |
Maximum thickness of bent steel plate | mm | 8（σs≤245 MPa） |
Maximum thickness of pre-bent steel plate | mm | 6（σs≤245 MPa） |
Upper roller diameter | mm | Φ190 |
Lower roller diameter | mm | Φ180 |
Side roller diameter | mm | Φ160 |
Minimum rolling diameter | mm | Φ380 |
Rolling speed | m/min | 4 |
Length of remaining straight edge | mm | ≤ 2.5 times thick |
Side roller adjustment speed | mm/min | ≥100 |
Lower roller adjustment speed | mm/min | ≥100 |
Motor power | Kw | 5.5 |
Dimension | mm | 4200*1400*1400 |
Weight | kg | 5000 |
1. Adopt unique pre-pressure relief technology to effectively avoid hydraulic shock and improve the life of pipeline and seal.
2. The hydraulic components are imported high-quality products to ensure the stability of the hydraulic system.
3. Each input and output port of the hydraulic system is equipped with corresponding detection points, which is convenient for maintenance and fault checking. The oil pump adopts the lower type and absorbs oil under positive pressure. At the same time, the filter, liquid level gauge, all have signaling devices, which can automatically alarm and prompt. In addition, the hydraulic station is independent of the machine base, which is convenient for repair and maintenance; and it is far away from the heat source.
4. System production is strictly carried out in accordance with international and industrial standards. The pipe radius is reasonable and not less than 90 °. The transition is round and slippery. The vibration damping pipe clamps are reasonably arranged to effectively avoid shock and vibration.
5. The system design fully considers high efficiency and energy saving, reduces power waste, and reduces heat sources.
6. Equipped with high-precision oil absorption and oil return filters to ensure the cleanliness of the system oil.
7. Provide common fault phenomena and troubleshooting methods for the hydraulic system of the plate rolling machine.
8. In order to ensure the manufacturing quality of the hydraulic system, the system is made according to the professional hydraulic manufacturer and national GB3766-83 "General Technical Conditions of Hydraulic System".
9. The oil tank is shot-blasted, pickled and surface cleaned, and the four walls are coated with oil-resistant varnish to ensure that the oil tank is clean. There is an air filter at the refueling point of the fuel tank to ensure the role of filtering oil and ventilation. In addition, a fine filter must be provided at the end of the oil suction pipe and the oil supply line.
1. Clearly define the thickness, width, and material of the processed sheet, match the roller length and rated pressure of the equipment to avoid inability to process.
2. Prioritize fully CNC closed-loop control to ensure bending accuracy ≤ 0.1mm and reduce manual operation errors.
3. The roller is made of quenched alloy steel with a surface hardness that meets the standard, avoiding wear and adapting to the processing specifications of the sheet metal.
4. The body is designed with an overall welded structure, which has strong rigidity, no deformation, and extends the service life of the equipment.
5. Confirm that the manufacturer's after-sales service is complete, provide installation and debugging training, and the warranty period is not less than 12 months.
1. We will select the appropriate rolling machine model based on your processing needs and provide you with a rolling solution.
2. We provide a complete set of export customs declaration and clearance documents, assist in handling logistics transportation, and ensure the safe delivery of equipment to designated overseas locations.
3. Support multilingual operation manuals and technical documents, equipped with professional bilingual customer service, timely response to inquiries and problem answers.
4. Provide remote installation and debugging guidance, and arrange technical personnel to go abroad for service to ensure the smooth operation of the equipment.
5. The warranty period is one year, during which spare parts are provided free of charge, and lifelong remote technical support is provided to ensure the long-term stable operation of the rolling machine.
Welcome to contact us for further negotiation.
